INTRODUCTION:
The ITD integrated buttons operation panel PC typically features a touchscreen display, allowing users to interact directly with the interface by tapping or swiping on the screen. In addition to the touchscreen functionality, the device incorporates physical buttons that are strategically placed on the panel for specific functions. These buttons may serve as shortcuts, control inputs, or dedicated keys for certain tasks, enhancing the overall user experience and efficiency. It is mainly used for industrial automation, manufacturing control systems, medical equipment interfaces, and more. The integration of physical buttons with a touchscreen interface aims to strike a balance between the convenience of touch interaction and the precision of dedicated buttons, catering to a wide range of user preferences and operational requirements.
FEATURES:
• Easy-to-clean, true flat front surface without bezel
• Flexible, reliable, and ruggedized touch screen computers for open platform HMI/SCADA
• Built-in function buttons for intuitive operation
• Eliminates dust and debris build-up at the edge and corners of the display
• Provides improved power efficiency and reduced consumption
• PCAP touch control with responding to a light touch to activate response
• Ruggedized levels of NEMA 12, NEMA 4, IP52, IP54, IP65 ratings for front panel
• Aluminum front bezel and steel chassis construction designed for harsh and industrial environments
• CE, FCC, RoHS Compliance
OPTIONALS:
• DC 24V, DC9-36V, AC100-240V
• Optical bonding, High brightness
• Resistive touch screen, tempered glass, AR/AG
• WIFI, 4G/5G, GPS
Specification:
| DISPLAY | |
| Panel | Cell Type/Glass Surface | TFT | |
| Size/ Aspect Ratio | 21.5”/16:9 | |
| Active Area/ Pixel Pitch | 476.64(H) x268.11(V)mm/0.24825× 0.24825mm | |
| Native Resolution/ Colors | 1920 x 1080/16.7M | |
| Brightness/ Contrast | 250cd/㎡/1000:1 | |
| Response Time/ Viewing Angle(Typical) | 5ms/89/89/89/89 | |
| Light Source | LED Backlight with 50000Hours’Lifetime | |
| SYSTEM |
| Item | Android Solution | X86 Solution 1 | X86 Solution 2 |
| CPU | ARM Quad Core Cortex-A17, 1.8GHz (RK3399/RK3568/RK3588 optional) | Intel® Celeron J1900//J4125/J6412 2.0GHz | Intel® Core i3/i5/i7 |
| Chipset | RK3288 | Intel Bay Trail SoC | Intel SoC Chipset |
| Memory | 2GB; 4GB Optional | Dual Channel, DDR3 1333/1600MHz Memory, Max.8GB; DDR4 SODIMM×1(Intel J4125/J6412) | 2×DDR3 1333/1600MHz SO-DIMM Slot, Max. 16GB DDR4 SODIMM ×2 (8th~11th gen.) |
| Storage | 8GB: 16GB/32GB/64GB Optional | 1×MSATA, 1×SATA 1×M.2 (not available for J1900) Default to 64GB SSD | 1×MSATA, 1×SATA 1×M.2 Default to 64GB SSD |
| Graphics | Supports max. 4K resolution | Intel HD Graphics (By CPU) | Intel HD/UHD Graphics (By CPU) |
| LAN | 1×10/100/1000Mbps Ethernet | 1× 10/100/1000Mbps Ethernet( Dual LAN optional) | 1×10/100/1000Mbps Ethernet( Dual LAN optional) |
| OS | Android 7.1/8/10/11 Linux Ubuntu(optional) | Windows 7/10, Linux Windows 11(available for J4125/J6412) | Windows 7/10, Linux Windows 11(available for 7th gen. or above) |
| GENERAL |
| Power | Input Voltage | DC 12V input |
| Operation/Power Saving | 18~30W |
| Environment Considerations | Operating Temperature | -10~60℃ (-20~70℃ optional) |
| Storage Temperature | -20~70℃ |
| Relative Humidity | 10%~90% |
